Offshore Pedestal Crane
>
|
|
| Place of Origin | Jiangsu, China |
| Brand Name | OUCO |
| Certification | ISO9001/CE/ABS/CCS/BV |
| Model Number | OUCO-TB-3T40M |
3t Telescopic Boom Hydraulic 40m Offshore Pedestal Crane
Product Description
OUCO Marine/Offshore 3T40M Telescopic boom crane is mainly used on the deck of bulk carrier or overload barge for handling a variety of cargo bulks.
It has several hoisting points to fit the demand of vessel usage, which are 3T40M, 40T6.5M, 10T25M, makes the crane with long outreach to complete the lifting job.
The cranes are available from 3–40 meters of crane boom, which have long range of usage. This 3t40m telescopic crane currently have been made several sets with ABS Class certificate, will be delivered within 3 months with stable and reliable quality based on clients’ usage and testings.
The availability of a telescopic or fixed jib extension on a telescopic boom is not only easy to attach and use, but it makes it possible to extend the reach of the crane boom by as much as 40 meter. With a jib, boom cranes are capable of reaching boom lengths as tall as 35 meter, which is very beneficial when placing loads at height or lifting personnel using a work platform.
Specification
| SWL | 3T@40M&40T6.5M |
| MAX WORKING RADIUS | 40m |
| MIN WORKING RADIUS | 3m |
| HOISTING SPEED | 0~15m/min |
| HOISTING HEIGHT | 35m |
| SLEWING SPEED | ~0.6r/min |
| SLEWING ANGLE | 360° |
| LUFFING TIME | ~ 90s |
| WORKING CONDITION |
TRIM ≤2° HEEL ≤5° |
| ELEC-MOTOR POWER | Y160L-4-H |
| POWER | 160kw |
| Speed | 1780r/min |
| POWER RESOURCE | AC440V/60HZ |
| PROTECT CLASS | IP44 |
| INSUKATE CLASS | F |
| WORKING TYPE | S1 |
Main Features And Advantages
1.Easy maintenance at all situation
2.Self contained unit with integrated hydraulic power pack
3.Fail-safe brakes on all movements
4.Fully enclosed and equipped operator cabin with air condition
5.The variable speed hoist will automatically adjust to the highest possible speed for the appropriate load
6.Technology from Germany
7.Base on many year's design and fabrication experience of crane and other similar equipment
8.Suitable for all kinds of ships and low power consumption and high efficiency
9.Welded and high strength box boom for easy maintenance
10.With Many safety protection devices---hook up limiter and overload limiter, emergency stop button
General Arrangement
Our company
OUCO Industry, was established in February 1984, covers an area of 48,000 square meters, construction area is 35,000 square meters.
OUCO headquartered in crane hometown of Jiangsu Province where representing most advanced machinery manufacturing level in China.
OUCO has more than 150 employees, 20 are technical staff. Among that has five senior titles, 10 mid-level titles, and a total of 50 welder (who has got CCS, ABS and other main institutions’ certification). It also has professional organization certificated flaw detection staff, the quality system audit staff, and inspection personnel, etc.
OUCO provides high quality handling solutions and access systems for the Crane, port industries and various non-standard structural parts. The company has its own developing, designing, and manufacturing capacity for products of metallurgical complete sets of equipment, marine cranes, truck cranes, boiler desulfurization and denitrification environmental protection products in air pollution control field. Company products are widely used in the metallurgical, ship, port, electricity, petroleum, building materials and chemical industries.
OUCO has subsidiaries in several countries and serves a global client base from strategic points in Europe, Asia, Africa, Australia and Middle East. It has an annual output of 11,000 tons of steel structure production capacity.
FAQ
1. Can this type work in hazardous environment?
Sure! We can customize for you, acid proof or explosion proof, no problem for that.
2. Can you provide the serious lifting tools?
Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
3. How can we install the crane?
Our senior engineer can be your side to do the installation guide service and training. Moreover, our best sales can visit your country.
4. Safety device
Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
