Hydraulic Power Marine / Deck Crane Telescopic Boom Pedestal

Basic Information
Place of Origin: Jiangsu, China
Brand Name: OUCO
Certification: CE, ISO
Model Number: OUCO-0.5T6M-TB
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Shipping Container/Wood Crate/nude
Delivery Time: 60 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per year
Product Name: BV Test Hydraulic Power Telescopic Boom Pedestal Marine/deck Crane Type: Telescopic Boom
Condition: New After-sales Service: Online Support, Video Technical Support, Free Spare Parts
Usage: Cargo Lifting Warranty: 1 Year
Material: Steel
High Light:

Hydraulic Power Marine Crane

,

Cargo lifting Marine Crane

,

Telescopic Boom Pedestal Marine Crane

BV test hydraulic power telescopic boom pedestal marine/deck crane

The boom extension is a telescopic inner section that allows a more flexible and wider operational radius and leaves the crane stored in a compact position. Low weight and a less complex design make our telescopic boom crane a maintenance-friendly product. The cranes are in operation at fishfarming vessels and bigger service vessels.Oucohydraulic jib booms give you the reach you want, in a crane that stores compactly and is easy to place. Continuous adjustment of the boom over the course of work results in a more efficient crane. Multiple booms ensure a Telescopic Boom crane will be able to meet your requirements for strength and agility. Years of severe duty on multiple US research vessels have proven our Telescopic Boom cranes' durability and performance. Capacities from 1 to 85 tons.Ouco telescopic boom cranes for the wind industry ensure safe and fast loading and unloading of supply vessels and flexible material handling, servicing as well as handling of other equipment on the substation. The wind cranes are customized to accommodate any sea state and optional features add extra functionality for safe operation. The Ouco telescopic boom cranes for the wind industry are designed according to customer requirements, rules, and regulations.



Product Parameters

SWL 0.5T
MAX WORKING RADIUS 6m
MIN WORKING RADIUS 1.5m
HOISTING SPEED ~10m/min(main hook)   ~30m/min (aux hook)
HOISTING HEIGHT 30m
SLEWING SPEED 0~0.5r/min
SLEWING ANGLE 360°
LUFFING TIME ~ 120s
WORKING CONDITION TRIM ≤2°HEEL ≤5°
ADVISED OIL FLOW 92L/min
MOTOR POWER 15kw
DEAD WRIGHT 2200KG
POWER RESOURCE 380v,50Hz,3P
PROTECT CLASS IP56
INSUKATE CLASS F
WORKING TYPE S1




GA Drawing

Hydraulic Power Marine / Deck Crane Telescopic Boom Pedestal 0

Packaking

Hydraulic Power Marine / Deck Crane Telescopic Boom Pedestal 1



Why Choose OUCO Marine Crane?

  1. OUCO uses special marine-grade steel plates, DH36 for better corrosion resistance and EH36 for -40°C conditions.
  2. The more symmetrical center design of the octagonal boom makes it have a bigger anti-bending capacity.
  3. OUCO Marine Crane can be telescoped and folded with a load.
  4. OUCO has simulated marine working conditions, with a Trim≤2° and Heel≤5°.
  5. OUCO uses fan coolers to ensure long-lasting operation of the crane at high temperatures.
  6. OUCO uses holding valves to ensure crane safety in case of hydraulic system failure.
  7. OUCO uses stainless steel grease nipples to avoid rusting under marine conditions.
  8. The anti-two block system, composed of a top limit and bottom limit, ensures the winch's safety.
  9. OUCO uses a precise step-less speed control valve.
  10. Emergency stop devices are installed on each crane.
  11. OUCO follows the C5M marine painting rules and uses world-famous paint brands.

                         Welcome to visit our factory!

Hydraulic Power Marine / Deck Crane Telescopic Boom Pedestal 2
