Yacht 2t 10m Telescopic Boom Hydraulic Deck Crane

Basic Information
Place of Origin: Jiangsu, China
Brand Name: OUCO
Certification: ISO9001/CE/ABS/CCS/BV
Model Number: OUCO-TB-2T10M
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Shipping Container/Wood Crate/nude
Delivery Time: 90 days
Supply Ability: 100 sets per year
SWL: 2t10m Material: Steel Structure
Warranty: 1 Year Type: Telescopic Boom
Working Condition: Marine Color: Customer Requirement
Max. Working Radius: 10m Min. Working Radius: 2m
High Light:

10m Hydraulic Deck Crane

,

2t Hydraulic Deck Crane

,

Telescopic Marine Davit Crane

Yacht 2t 10m Telescopic Boom Hydraulic Deck Crane



Product Description



OUCO Marine/Offshore Telescopic boom cranes are based on a pedestal slewing design with hydraulic cylinder luffing.

The boom extension is a telescopic inner section that allows a more flexible and wider operational radius in use and leaves the crane stored in a compact position.

The advantages of the telescopic cranes are low weight and less complex design making them maintenance-friendly.

The cranes are available from 5–40 meters of crane boom, which have long range of usage. OUCO Marine Telescopic cranes can be designed and manufactured by clients’ requirements in our own factory.



Main Features and advantages

The availability of a telescopic or fixed jib extension on a telescopic boom is not only easy to attach and use, but it makes it possible to extend the reach of the crane boom by as much as from 1 m to 40 meter. With a jib, boom cranes are capable of reaching boom lengths as tall as 35 meter, which is very beneficial when placing loads at height or lifting personnel using a work platform.

Specification

SWL 2T@10M
MAX WORKING RADIUS 10m
MIN WORKING RADIUS 2m
HOISTING SPEED 0~15m/min
HOISTING HEIGHT 20m
SLEWING SPEED ~0.8r/min
SLEWING ANGLE 360°
LUFFING TIME ~ 60s
EXTENSION TIME ~150s
WORKING CONDITION

TRIM ≤2°

HEEL ≤5°

ELEC-MOTOR POWER Y160L-4-H
POWER 45kw
Speed 1760r/min
POWER RESOURCE AC440V/60HZ
PROTECT CLASS IP44
INSUKATE CLASS F
WORKING TYPE S1

Yacht 2t 10m Telescopic Boom Hydraulic Deck Crane 0



General Arrangement

Yacht 2t 10m Telescopic Boom Hydraulic Deck Crane 1





Customer visiting

Yacht 2t 10m Telescopic Boom Hydraulic Deck Crane 2







Our Company

OUCO Industry, was established in February 1984, covers an area of 48,000 square meters, construction area is 35,000 square meters.



OUCO headquartered in crane hometown of Jiangsu Province where representing most advanced machinery manufacturing level in China.



OUCO has more than 150 employees, 20 are technical staff. Among that has five senior titles, 10 mid-level titles, and a total of 50 welder (who has got CCS, ABS and other main institutions’ certification). It also has professional organization certificated flaw detection staff, the quality system audit staff, and inspection personnel, etc.



OUCO provides high quality handling solutions and access systems for the Crane, port industries and various non-standard structural parts. The company has its own developing, designing, and manufacturing capacity for products of metallurgical complete sets of equipment, marine cranes, truck cranes, boiler desulfurization and denitrification environmental protection products in air pollution control field. Company products are widely used in the metallurgical, ship, port, electricity, petroleum, building materials and chemical industries.



OUCO has subsidiaries in several countries and serves a global client base from strategic points in Europe, Asia, Africa, Australia and Middle East. It has an annual output of 11,000 tons of steel structure production capacity.





FAQ

1. Can this type work in hazardous environment?
Sure! We can customize for you, acid proof or explosion proof, no problem for that.
2. Can you provide the serious lifting tools?
Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
3. How can we install the crane?
Our senior engineer can be your side to do the installation guide service and training. Moreover, our best sales can visit your country.
4. Safety device
Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
