| Place of Origin: | Jiangsu, China |
|---|---|
| Brand Name: | OUCO |
| Certification: | CE, ISO |
| Model Number: | OUCO-1.5T36.6M-TB-00 |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiation |
| Packaging Details: | Shipping Container/Wood Crate/nude |
| Delivery Time: | 60 days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 300 sets per year |
| Material: | Steel | Type: | Telescopic Boom |
|---|---|---|---|
| Condition: | New | After-sales Service: | Online Support, Video Technical Support, Free Spare Parts |
| Usage: | Cargo Lifting | Warranty: | 1 Year |
| High Light: | 36.6m telescopic boom crane,1.5t telescopic boom crane,marine telescopic boom crane |
||
The telescopic series of cranes offer a diverse product line for application in the Luxury Yacht, Oceanographic, Workboat, Oilfield, Cost Guard or Military industries. These cranes can also be further customized for use in these most demanding of work environments. All of the cranes in the Telescopic Boom line offer several key features that make them powerful solutions for the marine work environment. The most notable of these features include: Extended boom reach with the dexterity for accurate, safe, and efficient material handling.
Specifications
|
1 |
CRANE TYPE
|
1.5t @36.6m Max. Working radius:36.6m. Hydraulic Telescopic Boom offshore Crane |
| 2 | CERTIFICATION | ABS under sea state 2 |
| 3 | QUANTITY | 1 set |
| 4 | HEEL/TRIM | 5°/2° |
| 5 | AMBIENT TEMPERATURE | -9.9°C~+45°C |
| 6 | SWL | 1.5t @36.6m |
| 7 | MAX WORKING DADIUS | 36.6m |
| 8 | MIN WORKING DADIUS | 4m |
| 9 | HOISTING SPEED |
0~10m/min(main hook) ~30m/min (aux hook) |
| 10 | LIFTING HEIGHT | ~30m |
| 11 | SLEWING ANGLE | ~360° all free |
| 12 | SLEWING SPEED | 0~0.5r/min |
| 13 | LUFFER TIME | 120s |
| 14 | SELF WEIGHT OF CRANE | ~39t(Confirmed in approval drawing) |
| 15 | POWER SUPPLY | 415v,50Hz,3P |
Product Features
1. Easy maintenance at all situation
2. Self contained unit with integrated hydraulic power pack
3. Fail-safe brakes on all movements
4. Fully enclosed and equipped operator cabin with air condition
5. The variable speed hoist will automatically adjust to the highest possible speed for the appropriate load
6. Base on many year's design and fabrication experience of crane and other similar equipment
7. Suitable for all kinds of ships and low power consumption and high efficiency
8. Welded and high strength box boom for easy maintenance
9. With Many safety protection devices---hook up limiter and overload limiter, emergency stop button
