| Place of Origin: | Jiangsu, China |
|---|---|
| Brand Name: | OUCO |
| Certification: | CE, ISO |
| Model Number: | 2.5T22M-TB-MC |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiation |
| Packaging Details: | Shipping Container/Wood Crate/nude |
| Delivery Time: | 60 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 300 sets per year |
| Material: | Steel | Type: | Telescopic Boom |
|---|---|---|---|
| Working Radius: | Max. 22m | Model: | Marine Crane |
| Painting: | C5-M | Slewing Angle: | 360° |
| Application: | Vessel | OEM: | Welcomed |
| High Light: | 2.5t22m ship deck cranes,telescopic boom ship deck cranes,hydraulic marine deck davit crane |
||
2.5T22M Telescopic Boom Hydraulic Marine Deck Crane
OUCO Marine/Offshore telescopic boom compound marine cranes would be the type of effortless cranes with foldable and telescopic booms compound, which make full use of the cranes' strengths and flexibility when loading and unloading goods. OUCO Marine group can design the foldable cranes based on API-2C regulations and rules. OUCO 2.5T22M telescopic was delivered in 3 months time with full CCS Class and being installed in.
The TB series crane is designed as an electro-hydraulic driven telescopic boom crane, with integrated electro-hydraulic power unit, delivered as a complete unit ready for installation to vessels. The crane is equipped with hydraulic operated winch, hydraulic operated luffing and hydraulic operator extension and hydraulic operated slewing system.
The crane is installed with a rolled steel pedestal for bolting or welding to deck with a height of 1200mm and pedestal diameter is depend on the SWL of the crane. The standard TB crane will supply with an operator platform. Operator cabin is optional.
The crane and all it associated components / equipment shall be designed in accordance to any leading classification societies which is upon request. The crane shall be tested and adjusted ready for installation by welding or bolting to vessel deck. Power connection shall be provided for electrical supply through integrated electrical slip rings.
Specification
| 1 |
CRANE TYPE |
2.5t @22m Max. Working radius:22m. Hydraulic Telescopic Boom offshore Crane |
| 2 | CERTIFICATION | ABS under sea state 2 |
| 3 | QUANTITY | 1 set |
| 4 | HEEL/TRIM | 5°/2° |
| 5 | AMBIENT TEMPERATURE | -9.9°C~+45°C |
| 6 | SWL | 2.5t @22m |
| 7 | MAX WORKING DADIUS | 22m |
| 8 | MIN WORKING DADIUS | 4m |
| 9 | HOISTING SPEED |
0~10m/min(main hook) ~30m/min (aux hook) |
| 10 | LIFTING HEIGHT | ~30m |
| 11 | SLEWING ANGLE | ~360° all free |
| 12 | SLEWING SPEED | 0~0.5r/min |
| 13 | LUFFER TIME | 120s |
| 14 | SELF WEIGHT OF CRANE | ~39t(Confirmed in approval drawing) |
GA Drawing
Product Display
Product Process
Company Information
FAQ
1. Can this type work in hazardous environment?
Sure! We can customize for you, acid proof or explosion proof, no problem for that.
2. Can you provide the serious lifting tools?
Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
3. How can we install the crane?
Our senior engineer can be your side to do the installation guide service and training. Moreover, our best sales can visit your country.
4. Safety device
Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
